| Parameter | Value |
|---|---|
| Category | Headers, Male Pins |
| Manufacturer | Amphenol ICC (FCI) |
| Style | Board to Board or Cable |
| Series | BERGSTIK® |
| Features | - |
| Packaging | Bulk |
| Shrouding | Unshrouded |
| Part Status | Active |
| Termination | Solder |
| Applications | - |
| Contact Type | Male Pin |
| Contact Shape | Square |
| Mounting Type | Through Hole |
| Connector Type | Header, Breakaway |
| Fastening Type | Push-Pull |
| Number of Rows | 2 |
| Pitch - Mating | 0.100" (2.54mm) |
| Voltage Rating | - |
| Contact Material | Phosphor Bronze |
| Insulation Color | Black |
| Insulation Height | 0.100" (2.54mm) |
| Ingress Protection | - |
| Base Product Number | 77313 |
| Insulation Material | Thermoplastic |
| Number of Positions | 50 |
| Row Spacing - Mating | 0.100" (2.54mm) |
| Contact Finish - Post | Tin |
| Contact Length - Post | 0.114" (2.90mm) |
| Current Rating (Amps) | 3A per Contact |
| Operating Temperature | -65°C ~ 130°C |
| Mated Stacking Heights | - |
| Overall Contact Length | 0.480" (12.19mm) |
| Contact Finish - Mating | Gold or Gold, GXT™ |
| Contact Length - Mating | 0.266" (6.75mm) |
| Number of Positions Loaded | All |
| Material Flammability Rating | UL94 V-0 |
| Contact Finish Thickness - Post | 78.7µin (2.00µm) |
| Contact Finish Thickness - Mating | 30.0µin (0.76µm) |
