RPM
2550 RPM
Noise
35.0dB
Width
37.00mm
Series
12537JE
RoHS Compliant
Why Choose Us
Quality Warranty
Quality guarantee
ESD Safe
Anti-static protection
Global Shipping
Fast delivery
Quick Response
Fast RFQ
Request for Quote
Price not displayed? Please send an RFQ, and we will respond immediately.
MOQ1 pcs
Professional Packaging
Original Packaging
Factory sealed, ESD anti-static tray
Desiccant Protection
Humidity indicator card & silica gel included
Vacuum Sealing
Moisture barrier bag, nitrogen filled
Secure Boxing
Anti-vibration foam, shock-proof labeling
| Parameter | Value |
|---|---|
| Category | DC Brushless Fans (BLDC) |
| Manufacturer | NMB Technologies Corporation |
| RPM | 2550 RPM |
| Noise | 35.0dB |
| Width | 37.00mm |
| Series | 12537JE |
| Air Flow | 76.6 CFM (2.14m³/min) |
| Fan Type | Tubeaxial |
| Features | Auto Restart |
| Packaging | Box |
| Part Status | Active |
| Termination | 2 Wire Leads |
| Bearing Type | Ball |
| Power (Watts) | 1.69 W |
| Voltage Range | 7 ~ 13.2VDC |
| Approval Agency | - |
| Static Pressure | 0.170 in H2O (42.3 Pa) |
| Voltage - Rated | 12VDC |
| Lifetime @ Temp. | 70000 Hrs @ -20°C |
| Material - Blade | Plastic |
| Material - Frame | Plastic |
| Size / Dimension | Square - 125.4mm L x 125.4mm H |
| Ingress Protection | - |
| Base Product Number | 12537JE |
| Current Rating (Amps) | 0.140A |
| Operating Temperature | -40 ~ 104°F (-40 ~ 40°C) |
