Type
Invasive
Series
FIS 1X5
Weight
0.017 lb (7.71 g)
Packaging
Tube
RoHS Compliant
Why Choose Us
Quality Warranty
Quality guarantee
ESD Safe
Anti-static protection
Global Shipping
Fast delivery
Quick Response
Fast RFQ
Request for Quote
Price not displayed? Please send an RFQ, and we will respond immediately.
MOQ1 pcs
Professional Packaging
Original Packaging
Factory sealed, ESD anti-static tray
Desiccant Protection
Humidity indicator card & silica gel included
Vacuum Sealing
Moisture barrier bag, nitrogen filled
Secure Boxing
Anti-vibration foam, shock-proof labeling
| Parameter | Value |
|---|---|
| Category | Current Sense Transformers |
| Manufacturer | Pulse Electronics |
| Type | Invasive |
| Series | FIS 1X5 |
| Weight | 0.017 lb (7.71 g) |
| Ratings | - |
| Packaging | Tube |
| Inductance | 76 mH |
| Part Status | Active |
| Manufacturer | Pulse Electronics |
| Current Ratio | - |
| Mounting Type | Through Hole |
| ET (Volt-Time) | 700VµS |
| Frequency Range | 500kHz Max |
| Size / Dimension | 0.693" L x 0.591" W (17.60mm x 15.00mm) |
| Termination Style | PC Pin |
| DC Resistance (DCR) | 4.5Ohm Max |
| Height - Seated (Max) | 0.492" (12.50mm) |
| Turns Ratio - Primary:Secondary | 1:200 |
