Pitch
0.100" (2.54mm), Full
Length
0.239" (6.08mm)
Series
KR
Circuit
SPST
RoHS Compliant
Why Choose Us
Quality Warranty
Quality guarantee
ESD Safe
Anti-static protection
Global Shipping
Fast delivery
Quick Response
Fast RFQ
Request for Quote
Price not displayed? Please send an RFQ, and we will respond immediately.
MOQ1 pcs
Professional Packaging
Original Packaging
Factory sealed, ESD anti-static tray
Desiccant Protection
Humidity indicator card & silica gel included
Vacuum Sealing
Moisture barrier bag, nitrogen filled
Secure Boxing
Anti-vibration foam, shock-proof labeling
| Parameter | Value |
|---|---|
| Category | DIP Switches |
| Manufacturer | CIT Relay and Switch |
| Pitch | 0.100" (2.54mm), Full |
| Length | 0.239" (6.08mm) |
| Series | KR |
| Circuit | SPST |
| Features | - |
| Washable | No |
| Packaging | Tube |
| Part Status | Active |
| Manufacturer | CIT Relay and Switch |
| Actuator Type | Slide (Standard) |
| Body Material | Polybutylene Terephthalate (PBT) |
| Mounting Type | Through Hole, Right Angle |
| Actuator Level | Flush, Recessed |
| Contact Finish | Gold |
| Voltage Rating | 24VDC |
| Electrical Life | 2,000 Cycles |
| Mechanical Life | - |
| Contact Material | Phosphor Bronze |
| Termination Style | PC Pin |
| Height Above Board | 0.378" (9.60mm) |
| Number of Positions | 2 |
| Current Rating (Amps) | 25mA |
| Operating Temperature | -40°C ~ 85°C |
Package
-
MSL
-
