Includes
4 pcs - 1 Connector, 1 Contact, 1 Lockwasher, 1 Nut
Impedance
50 Ohms
Packaging
Bulk
Body Finish
White Bronze
RoHS Compliant
Why Choose Us
Quality Warranty
Quality guarantee
ESD Safe
Anti-static protection
Global Shipping
Fast delivery
Quick Response
Fast RFQ
Request for Quote
Price not displayed? Please send an RFQ, and we will respond immediately.
MOQ1 pcs
Professional Packaging
Original Packaging
Factory sealed, ESD anti-static tray
Desiccant Protection
Humidity indicator card & silica gel included
Vacuum Sealing
Moisture barrier bag, nitrogen filled
Secure Boxing
Anti-vibration foam, shock-proof labeling
| Parameter | Value |
|---|---|
| Category | Coaxial Connector (RF) Assemblies |
| Manufacturer | Rosenberger |
| Series | - |
| Features | - |
| Includes | 4 pcs - 1 Connector, 1 Contact, 1 Lockwasher, 1 Nut |
| Impedance | 50 Ohms |
| Packaging | Bulk |
| Body Finish | White Bronze |
| Cable Group | RG-402 (.141" Semi Rigid) |
| Part Status | Active |
| Body Material | Brass |
| Housing Color | Silver |
| Mating Cycles | 500 |
| Mounting Type | Panel Mount |
| Connector Type | Jack, Female Socket |
| Fastening Type | Threaded |
| Insertion Loss | - |
| Voltage Rating | 500 V |
| Connector Style | TNC |
| Frequency - Max | 10 GHz |
| Number of Ports | 1 |
| Mounting Feature | Bulkhead - Front Side Nut |
| Ingress Protection | - |
| Shield Termination | Solder |
| Base Product Number | 56K611 |
| Contact Termination | Solder |
| Dielectric Material | Polytetrafluoroethylene (PTFE) |
| Operating Temperature | -45°C ~ 85°C |
| Center Contact Plating | Gold |
| Center Contact Material | Bronze |
