Note
Contacts Not Included; Jam Nut Not Included
Type
For Male Pins
Series
HDP20
Features
Dust Cap, Ring Adapter
RoHS Compliant
Why Choose Us
Quality Warranty
Quality guarantee
ESD Safe
Anti-static protection
Global Shipping
Fast delivery
Quick Response
Fast RFQ
Request for Quote
Price not displayed? Please send an RFQ, and we will respond immediately.
MOQ1 pcs
Professional Packaging
Original Packaging
Factory sealed, ESD anti-static tray
Desiccant Protection
Humidity indicator card & silica gel included
Vacuum Sealing
Moisture barrier bag, nitrogen filled
Secure Boxing
Anti-vibration foam, shock-proof labeling
| Parameter | Value |
|---|---|
| Category | Circular Connector Housings |
| Manufacturer | TE Connectivity Deutsch Connectors |
| Note | Contacts Not Included; Jam Nut Not Included |
| Type | For Male Pins |
| Series | HDP20 |
| Features | Dust Cap, Ring Adapter |
| Includes | - |
| Packaging | Bulk |
| Shielding | Unshielded |
| Orientation | Keyed |
| Part Status | Active |
| Contact Size | 16 (5), 20 (42) |
| Contact Type | Crimp |
| Manufacturer | TE Connectivity Deutsch Connectors |
| Shell Finish | - |
| Contact Shape | Circular |
| Housing Color | Black, Blue |
| Mounting Type | Panel Mount |
| Connector Type | Receptacle Housing |
| Fastening Type | Bayonet Lock |
| Shell Material | Polyamide (PA66), Nylon 6/6, Glass Filled |
| Insert Material | Polyetherimide (PEI) |
| Shell Size, MIL | - |
| Mounting Feature | Bulkhead - Front Side Nut |
| Ingress Protection | IP68 - Dust Tight, Waterproof |
| Base Product Number | HDP24 |
| Number of Positions | 47 |
| Shell Size - Insert | 24-47 |
| Operating Temperature | -55°C ~ 125°C |
| Material Flammability Rating | UL94 V-1 |
